Weidmuller 1155490000

Name: PCB Plug-in Connector, Male Header with Closed Side, THT
Brand: Weidmuller
SKU: 1155490000

PCB Plug-in Connector, Male Header with Closed Side, THT

1 / 8

Manufacturer catalogue image

Product Description

The PCB Plug-in Connector, Male Header with Closed Side, THT is a specialized component designed for reliable and efficient through-hole solder connections. Featuring a 5.08 mm pitch and comprising 17 poles at a 90° angle, this connector ensures secure and stable connections in various electronic applications. The solder pin length of 3.2 mm and tinned finish enhance its durability and conductivity, while the closed side design provides additional protection and stability during installation. Packaged in a box, this connector is easy to store and transport, making it an ideal choice for both manufacturing and maintenance environments.

Engineered to meet stringent industry standards, this connector is suitable for a wide range of applications, including industrial automation, control systems, and electronic devices. Its robust construction and reliable performance make it a preferred choice for technical buyers seeking high-quality connectivity solutions.

Send Inquiry

Payment methods:

Offer details

Best offer from:: Trusted supplier — Italy, member since 2021, 10–19 employees
Availability:: 0 pcs.
On Request
Updated at: 05-09-2026
Warranty:: 12 months
Condition:: New Factory Sealed

New Factory Sealed - A brand-new, unused, unopened, undamaged item in its original manufacturer-sealed packaging.

The Seller is responsible for shipping the product and invoicing

Specifications

Brand: Weidmuller
Institute (cURus): cURus
Certificate No. (cURus): E60693
Rated voltage (Use group B / UL 1059): 300 V
Rated voltage (Use group D / UL 1059): 300 V
Rated current (Use group B / UL 1059): 18.5 A
Rated current (Use group D / UL 1059): 10 A
