Siemens 3RK2400-2CG00-2AA2
Siemens AS-I MODUL SC22.5 4DI/4DQ
1 / 1
Manufacturer catalogue image
Product Description
RoHS CompliantLifecycle Status:
The Siemens AS-I MODUL SC22.5 4DI/4DQ is a versatile and efficient AS-i SlimLine module designed for control cabinet operations. This module features 4 digital inputs and 4 digital outputs, making it an ideal solution for various industrial automation applications. The module supports A/B slave (Spec. 3.0) configuration and is compliant with the AS-Interface protocol, ensuring seamless integration into existing systems.
With a compact overall width of 45 mm, the module is designed for easy installation and space-saving in control cabinets. The screw terminals provide secure and reliable electrical connections for both inputs and outputs. The module operates with an external additional supply (AUX POWER) of 20 to 30 V DC, which must comply with VDE 0106 (PELV), protection class III.
The Siemens AS-I MODUL SC22.5 4DI/4DQ offers short-circuit and overload-resistant sensor supply, ensuring reliable performance even in demanding environments. The module's status display includes yellow LEDs for I/Os, a green LED for AS-Interface, and a red LED for FAULT, providing clear and immediate visual feedback on the module's status.
Designed for durability, the module operates within a wide ambient temperature range of -25°C to +70°C and has an IP20 protection class. It can be mounted on a 35 mm standard rail or wall-mounted using push-in lugs, offering flexibility in installation options.
Applications: This module is suitable for various industrial automation applications, including factory...
Send Inquiry
Payment methods:
Offer details
- Best offer from:
Trusted supplier — Poland, member since 2022, 1–4 employees- Availability:
- 2 pcs.In-StockUpdated at: 13-09-2026
- Warranty:
- 6 months
- Condition:
- New Factory Sealed
New Factory Sealed - A brand-new, unused, unopened, undamaged item in its original manufacturer-sealed packaging.
The Seller is responsible for shipping the product and invoicing
Specifications
- Brand
- Siemens
- Design of the product
- SlimLine S22.5 - I/O modules for operation in the control cabinet
- Design of the slave type
- A/B slave (Spec. 3.0)
- I/O configuration
- 4 inputs / 4 outputs
- Protocol supported
- AS-Interface protocol
- Protection class
- IP20
- Operating voltage
- 26.5 ... 31.6 V
