Weidmuller 1148100000
PCB Plug-In Connector SL 5.08HC/04/90B 3.2SN OR BX
Product Description
The SL 5.08HC/04/90B 3.2SN OR BX connector features a compact design with a pitch of 5.08 mm, making it suitable for various PCB applications. It has a 90° outgoing elbow and is equipped with 4 poles, each with a solder pin length of 3.2 mm. The connector is suitable for surface mounting with a THT solder connection.
Rated for a maximum voltage of 300 V and a current of 18.5 A (for use group B), it complies with both UL 1059 and IEC standards, ensuring reliable performance in diverse conditions. The insulation material is PA GF, colored orange, and it meets a Comparative Tracking Index (CTI) of ≥ 550.
With a robust design, the connector operates effectively within a temperature range of -50 °C to 100 °C, and is rated for up to 25 plugging cycles. The product is packaged in a box with specific dimensions for easy storage and handling.
Offer details
- Best offer from:
Trusted supplier — Italy, member since 2021, 10–19 employees- Availability:
- 0 pcs.On RequestUpdated at: 14-09-2026
- Warranty:
- 12 months
- Condition:
- New Factory Sealed
Specifications
- Brand
- Weidmuller
- Institute (cURus)
- cURus
- Certificate No. (cURus)
- E60693
- Rated voltage (Use group B / UL 1059)
- 300 V
- Rated voltage (Use group D / UL 1059)
- 300 V
- Rated current (Use group B / UL 1059)
- 18.5 A
- Rated current (Use group D / UL 1059)
- 10 A
