Weidmuller 1939371000

This M12 connector cable features a total length of 10 meters and is equipped with 3 poles. The cable is designed without a connector at one end and utilizes an angled socket configuration. Constructed from PUR for the sheath material, it ensures flexibility and durability within a temperature range of -25 to +80 °C. The connector meets the IEC 61076-2-101 standard and provides a rated voltage of 250 V and a rated current of 4 A.

With a gold-plated contact surface and a protection degree of IP65, IP66, IP67, IP68 when properly mounted, it is suitable for a variety of environmental conditions. The cable is not shielded, and the outer diameter is maintained at 4.3 ± 0.2 mm. For installation, the tightening torque is recommended between 0.8 - 1.2 Nm and it supports up to 100 plugging cycles.

Further enhancing its utility, the cable is made to withstand bending cycles of up to 2 million and is hydrolysis and microbe resistant. It adheres to various safety standards, including UL1581 for flame resistance. The designation code for this product is SAIV-M12BW-2/4-10U.
