Schneider Electric
HOM2150
1 / 6
Description
Active Mature
Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 150 A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connections are box lugs that will accept 1 wires. The box lugs will accept a wire range of 4 AWG to 2/0 AWG copper or aluminum wire. This circuit breaker has a height of 3.13 inches, a width of 2.0 inch and depth of 2.98 inches. HOM Homeline miniature circuit breakers are UL Listed.- Country of Origin
- MX
- Part Number
- HOM2150
- Tariff Code
- 8536200040
- EAN
- 39121603
- UPC
- 785901065838
- UNSPSC
- 39121603
Payment methods:
- Best offer from:
Trusted Automa.Net Supplier- Availability:
- 32 pcs.In-StockUpdated at: 21-11-2024
- Estimated Delivery:
- On Request
- Condition:
- New Surplus
New Surplus - A new, unused, undamaged item without a manufacturer guarantee. The item may come without original packaging or in replacement packaging. If provided, the box may have been opened.
Secure Payment Process
Return & Refund Policies
Shipping Policies
Warranty Policies
Environment
- Ambient Air Temperature For Operation
- 40 °C
Contractual warranty
- Warranty
- Lifetime
Offer Sustainability
- Rohs Exemption Information
- Yes
- Mercury Free
- Yes
- Environmental Disclosure
- ENVPEP1308001
- Sustainable Offer Status
- Green Premium product
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information.
- Circularity Profile
- N/A
- Eu Rohs Directive
- Compliant with Exemptions
Complementary
- Height
- 3.13 in
- Tightening Torque
- 4.0-4.0 N.m (AWG 4...AWG 2/0)
- Width
- 2 in
- Depth
- 2.98 in
Specifications
- Product Certifications
- UL Listed
- Circuit Breaker Type
- standard
- Range Of Product
- Homeline
- Number Of Spaces Required
- 2
- Product Or Component Type
- miniature circuit-breaker
- Circuit Breaker Application
- HACR rated
- Mounting Mode
- plug-in
- Short-Circuit Current
- 10 kA
- Poles Description
- 4P
- Electrical Connection
- box lugs
- Line Rated Current
- 150 A
- [Ue] Rated Operational Voltage
- 120/240 V AC
- Awg Gauge
- 1 x AWG 4...300 kcmil ( aluminium/copper )
