GV4P50B

Name: Motor circuit breaker, TeSys GV4, 3P, 50A, Icu 25kA, thermal magnetic, Everlink terminals
Brand: Schneider Electric
SKU: GV4P50B
Availability: InStock

1 / 1

Description

Active Mature

TeSys GV motor circuit breaker, 3 poles (3P), 50A/690V, for protection of 3-phase motors 11-22kW@400V. It provides thermal magnetic protection and additional motor protection functions, breaking capacity Icu 25kA@400V, start-stop control by rotary handle, connection by Everlink BTR screw terminals. Thermal protection adjustable by dials with a setting current Ir in range 20-50A and a selectable tripping class 10 or 20, magnetic protection at 17 In. Additional protections have fixed pick-up and include short time delay protection Isd at 13 Ir, phase unbalance and loss protection, ground fault protection. It makes internal locations available for additional auxiliary contact blocks (OF, SD), and voltage trip units (MN, MX). Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), Green Premium compliant (RoHS/REACh).

Country of Origin: PL
Part Number: GV4P50B
Tariff Code: 85362010
EAN: 3606481310125

£333.00

net

£370.00

Shipping from:

£35.00

Payment methods:

Best offer from:: Trusted Automa.Net Supplier
Availability:: 1 pc.
In-Stock
Updated at: 21-11-2024
Warranty:: 6 months
Estimated Delivery:: 25-26 November to United Kingdom
Condition:: New Factory Sealed

New Factory Sealed - A brand-new, unused, unopened, undamaged item in its original manufacturer-sealed packaging.

Shipping Information

Secure Payment Process

Return & Refund Policies

Shipping Policies

Warranty Policies

Environment

Product Certifications: IEC || UL || CSA || CCC || EAC || ATEX || EU-RO MR
Ik Degree Of Protection: IK07 IEC 62262
Ambient Air Temperature For Operation: -25-70 °C
Standards: CSA C22.2 No 60947-4-1 || UL 60947-4-1 || EN/IEC 60947-4-1 || EN/IEC 60947-2
Climatic Withstand: IACS E10
Pollution Degree: 3
Ambient Air Temperature For Storage: -50-85 °C
Ip Degree Of Protection: IP40 IEC 60529
Operating Altitude: 5000 m
Fire Resistance: 960 °C IEC 60695-2-11

Contractual warranty

Warranty: 18 months

Offer Sustainability

Rohs Exemption Information: Yes
Mercury Free: Yes
Environmental Disclosure: ENVPEP1704004EN
Sustainable Offer Status: Green Premium product
Pvc Free: Yes
Reach Regulation: Reference contains Substances of Very High Concern above the threshold
Weee: The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
China Rohs Regulation: Product out of China RoHS scope. Substance declaration for your information.
Circularity Profile: ENVEOLI1704004EN
Eu Rohs Directive: Compliant with Exemptions
Halogen Content Performance: Halogen free plastic parts product

Complementary

Mechanical Robustness: vibrations +/- 1 mm 2...13.2 Hz IEC 60068-2-6 || vibrations 0.7 gn 13.2...100 Hz IEC 60068-2-6 || shocks 15 gn 11 ms IEC 60068-2-27
Line Rated Current: 50 A
[Ue] Rated Operational Voltage: 690 V AC 50/60 Hz IEC 60947-2
Height: 155 mm
Phase Failure Sensitivity: yes IEC 60947-4-1
Rated Duty: continuous IEC 60947-4-1
Magnetic Tripping Current: 850-850 A
[Ith] Conventional Free Air Thermal Current: 115 A IEC 60947-4-1
Motor Power Kw: 11-11 kW 400...415 V AC 50/60 Hz || 15-15 kW 500 V AC 50/60 Hz || 18.5-18.5 kW 660...690 V AC 50/60 Hz || 15-15 kW 400...415 V AC 50/60 Hz || 18.5-18.5 kW 400...415 V AC 50/60 Hz || 22-22 kW 400...415 V AC 50/60 Hz || 18.5-18.5 kW 500 V AC 50/60 Hz || 22-22 kW 500 V AC 50/60 Hz || 30-30 kW 500 V AC 50/60 Hz || 22-22 kW 660...690 V AC 50/60 Hz || 30-30 kW 660...690 V AC 50/60 Hz || 37-37 kW 660...690 V AC 50/60 Hz || 45-45 kW 660...690 V AC 50/60 Hz
Maximum Operating Rate: 25 cyc/h
Operating Position: any position
Connections - Terminals: EverLink BTR screw connectors top) 1 1.5-70 mm² - solid || EverLink BTR screw connectors top) 1 1.5-50 mm² - flexible || EverLink BTR screw connectors bottom) 1 2.5-95 mm² - solid || EverLink BTR screw connectors bottom) 1 2.5-70 mm² - flexible
Utilisation Category: category A IEC 60947-2 || AC-3 IEC 60947-4-1
Net Weight: 1.6 kg
[Uimp] Rated Impulse Withstand Voltage: 8 kV IEC 60947-2
Control Type: rotary handle
Power Dissipation Per Pole: 4.6 W
Electrical Durability: 20000 cycles AC-3 440 V In/2 || 10000 cycles AC-3 440 V In
Breaking Capacity: 50 kA Icu 220...240 V AC 50/60 Hz IEC 60947-2 || 25 kA Icu 380...415 V AC 50/60 Hz IEC 60947-2 || 20 kA Icu 440 V AC 50/60 Hz IEC 60947-2 || 10 kA Icu 500 V AC 50/60 Hz IEC 60947-2 || 35 kA 208Y/120 V AC 50/60 Hz UL 60947 || 35 kA 240 V AC 50/60 Hz UL 60947 || 18 kA 480Y/277 V AC 50/60 Hz UL 60947 || 14 kA 600Y/347 V AC 50/60 Hz UL 60947
Suitability For Isolation: yes IEC 60947-1
[Ui] Rated Insulation Voltage: 800 V AC 50/60 Hz IEC 60947-2
Tightening Torque: 9 N.m 16-95 mm² || 5 N.m 1.5-10 mm²
Mechanical Durability: 40000 cycles
Poles Description: 3P
Color: Gray RAL 7016)
Width: 81 mm
Depth: 165 mm
