Schneider Electric GV4PE80B
Motor circuit breaker, TeSys GV4, 3P, 80A, Icu 25kA, thermal magnetic, Everlink terminals
1 / 1
Manufacturer catalogue image
Product Description
Lifecycle Status:
The Schneider Electric TeSys GV4 motor circuit breaker is a 3-poled, 80A/690V device designed to protect 3-phase motors with power ratings ranging from 22-37kW at 400V. This product provides thermal magnetic protection and additional motor protection functions, boasting a breaking capacity of Icu 25kA@400V.
The circuit breaker features start-stop control via a toggle switch and is equipped with Everlink BTR screw terminals for easy connection. Thermal protection can be adjusted by dials with a setting current Ir in the range of 40-80A, offering selectable tripping classes of 10 or 20. Magnetic protection is set at 17 In.
This product also includes additional protections with fixed pick-up values and features such as short time delay protection Isd at 13 Ir, phase unbalance and loss protection, and ground fault protection. It offers internal locations for auxiliary contact blocks (OF, SD) and voltage trip units (MN, MX).
The Schneider Electric TeSys GV4 motor circuit breaker is multi-standard certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), compliant with Green Premium standards (RoHS/REACh).
Send Inquiry
Payment methods:
Offer details
- Best offer from:
Trusted supplier — Romania, member since 2023, 1–4 employees- Availability:
- 1 pc.On RequestUpdated at: 22-08-2026
- Condition:
- New Surplus
New Surplus - A new, unused, undamaged item without a manufacturer guarantee. The item may come without original packaging or in replacement packaging. If provided, the box may have been opened.
The Seller is responsible for shipping the product and invoicing
Specifications
- Brand
- Schneider Electric
- Product Certifications
- IEC || UL || CSA || CCC || EAC || ATEX || EU-RO MR
- Ik Degree Of Protection
- IK07 IEC 62262
- Ambient Air Temperature For Operation
- -25-70 °C
- Standards
- CSA C22.2 No 60947-4-1 || UL 60947-4-1 || EN/IEC 60947-4-1 || EN/IEC 60947-2
- Climatic Withstand
- IACS E10
- Pollution Degree
- 3
